20700011001

Active

HARTING Technology Group

HAN ID MODULE ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

HARTING Technology Group

HAN ID MODULE ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	20700011001

Color	Gray
Connector Type	Module
Gender	Male
Housing Material	Polycarbonate (PC)
Material Flammability Rating	UL94 V-0
Number of Positions	6
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	0 °C
Termination Style	Tension Clamp

Part	Number of Positions	Housing Material	Gender	Material Flammability Rating	Termination Style	Operating Temperature [Max]	Operating Temperature [Min]	Connector Type	Color
HARTING Technology Group 20700011001	6	Polycarbonate (PC)	Male	UL94 V-0	Tension Clamp	70 °C	0 °C	Module	Gray

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Male Module Gray 6 Position Tension Clamp
