AA15D0512A
ObsoleteDelta Electronics
AC/DC CONVERTER 5V 12V 15W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AA15D0512A
ObsoleteDelta Electronics
AC/DC CONVERTER 5V 12V 15W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AA15D0512A |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cUL, UL, CE |
| Current - Output (Max) | 625 mA |
| Current - Output (Max) | 1.5 A |
| Efficiency | 72 % |
| Features | Universal Input |
| Line Regulation | 0.5 % |
| Load Regulation | 2.5 % |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Package / Case | 7-DIP Module, 6 Leads |
| Power (Watts) | 15 W |
| Size / Dimension [x] | 74 mm |
| Size / Dimension [x] | 2.91 " |
| Size / Dimension [y] | 54 mm |
| Size / Dimension [y] | 2.13 in |
| Size / Dimension [z] | 0.77 " |
| Size / Dimension [z] | 19.5 mm |
| Standard Number | 60950-1 |
| Type | Enclosed |
| Voltage - Output 1 | 5 V |
| Weight | 161.93 g |
| Weight | 0.357 lb |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
AA15D Series
Enclosed AC DC Converters 2 Output 5V 1.5A, 625mA 85 ~ 264 VAC Input
