DPT1.5/3GN

Active

MEAN WELL USA Inc.

1.5MM/3 CONNECTION/GRAY/PUSH IN

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

1.5MM/3 CONNECTION/GRAY/PUSH IN

Technical Specifications

Parameters and characteristics for this part

Specification	DPT1.5/3GN

Color	Green
Current - IEC	17.5 A
Current - UL	5 A
Material - Insulation	Polyamide (PA66), Nylon 6/6
Material Flammability Rating	UL94 V-0
Number of Levels	1
Stripping Length [Max]	10 mm
Stripping Length [Min]	8 mm
Terminal - Width [y]	3.5 mm
Termination Style	Push In
Type	Feed Through
Voltage - IEC	500 V
Voltage - UL	600 V
Wire Gauge or Range - AWG [Max]	26 AWG
Wire Gauge or Range - AWG [Min]	14 AWG
Wire Gauge or Range - mm² [Max]	1.5 mm²
Wire Gauge or Range - mm² [Min]	0.14 mm²

Part	Type	Number of Levels	Stripping Length [Min]	Stripping Length [Max]	Wire Gauge or Range - mm² [Min]	Wire Gauge or Range - mm² [Max]	Color	Current - UL	Current - IEC	Terminal - Width [y]	Material Flammability Rating	Termination Style	Material - Insulation	Voltage - IEC	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Voltage - UL
MEAN WELL USA Inc. DPT1.5/3GN	Feed Through	1	8 mm	10 mm	0.14 mm²	1.5 mm²	Green	5 A	17.5 A	3.5 mm	UL94 V-0	Push In	Polyamide (PA66) Nylon 6/6	500 V	26 AWG	14 AWG	600 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 1.68

General part information

Terminal Block Connector 3 Position Feed Through Green 14-26 AWG
