FXPT03200

Active

AMPHENOL PCD

TERM BLOCK PLUG 3POS 5.08MM

Search across all available documentation for this part.

Active

AMPHENOL PCD

TERM BLOCK PLUG 3POS 5.08MM

Technical Specifications

Parameters and characteristics for this part

Specification	FXPT03200

Color	Black
Contact Material	Copper Alloy
Contact Mating Finish	Tin
Housing Material	Polyphenylene Oxide (PPO)
Insulation Height	0.69 "
Insulation Height	17.53 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Levels	2
Operating Temperature	105 C
Pitch [x]	0.2 in
Pitch [x]	5.08 mm
Plug Wire Entry	90 °
Positions Per Level	2, 1
Termination Style	Screw with Captive Plate
Torque - Screw	10 Lb-In
Torque - Screw	1.13 Nm
Type	Plug, Female Sockets
Voltage - UL	300 V
Wire Gauge or Range - AWG [Max]	26 AWG
Wire Gauge or Range - AWG [Min]	12 AWG

Part	Operating Temperature	Positions Per Level	Termination Style	Mounting Type	Plug Wire Entry	Type	Torque - Screw	Torque - Screw	Number of Levels	Insulation Height	Insulation Height	Contact Material	Housing Material	Contact Mating Finish	Material Flammability Rating	Color	Voltage - UL	Pitch [x]	Pitch [x]	Wire Gauge or Range - AWG [Min]	Wire Gauge or Range - AWG [Max]
AMPHENOL PCD FXPT03200	105 C	1 2	Screw with Captive Plate	Free Hanging (In-Line)	90 °	Plug Female Sockets	10 Lb-In	1.13 Nm	2	0.69 "	17.53 mm	Copper Alloy	Polyphenylene Oxide (PPO)	Tin	UL94 V-0	Black	300 V	0.2 in	5.08 mm	12 AWG	26 AWG

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Position Terminal Block Plug, Female Sockets 0.200" (5.08mm) 90° Free Hanging (In-Line)

Technical documentation and resources

No documents available
