VUI72-16NOXT

Active

IXYS

BRIDGE RECT 3P 1.6KV 75A V1A-PAK

Search across all available documentation for this part.

Active

IXYS

BRIDGE RECT 3P 1.6KV 75A V1A-PAK

Technical Specifications

Parameters and characteristics for this part

Specification	VUI72-16NOXT

Current - Average Rectified (Io)	75 A
Current - Reverse Leakage @ Vr	40 µA
Diode Type	Three Phase
Mounting Type	Chassis Mount
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-40 °C
Package / Case	V1A-PAK
Supplier Device Package	V1A-PAK
Technology	Standard
Voltage - Forward (Vf) (Max) @ If	1.1 V
Voltage - Peak Reverse (Max)	1.6 kV

Part	Operating Temperature [Max]	Operating Temperature [Min]	Current - Average Rectified (Io)	Package / Case	Voltage - Peak Reverse (Max)	Technology	Mounting Type	Supplier Device Package	Current - Reverse Leakage @ Vr	Voltage - Forward (Vf) (Max) @ If	Diode Type
IXYS VUI72-16NOXT	150 °C	-40 °C	75 A	V1A-PAK	1.6 kV	Standard	Chassis Mount	V1A-PAK	40 µA	1.1 V	Three Phase

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Bridge Rectifier Three Phase Standard 1.6 kV Chassis Mount V1A-PAK
