44440-501
ActiveLaird Thermal Systems, Inc.
PELTIER CP10,71,05,L1,W4.5
Deep-Dive with AI
Search across all available documentation for this part.
44440-501
ActiveLaird Thermal Systems, Inc.
PELTIER CP10,71,05,L1,W4.5
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 44440-501 |
|---|---|
| Current - Max [Max] | 4 A |
| Delta Tmax @ Th | 25 °C |
| Features | Non-Sealed, Lapped, Lead Wires |
| Height [z] | 3.2 mm |
| Number of Stages | 1 |
| Operating Temperature | 80 °C |
| Resistance | 1.81 Ohms |
| Size / Dimension | Square |
| Size / Dimension [x] | 23 mm |
| Size / Dimension [y] | 23 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 32.17 | |
| 20 | $ 29.43 | |||
| 100 | $ 26.87 | |||
Description
General part information
44440 Series
Peltier Module 19.0W @ 25°C 4 A 80°C
Documents
Technical documentation and resources
