51105C

Active

Murata Power Solutions Inc.

CHOKE, COMMON MODE, 1 MH, 5100 SERIES, 3.3 A, 18MM X 10MM X 24MM

Search across all available documentation for this part.

Active

Murata Power Solutions Inc.

CHOKE, COMMON MODE, 1 MH, 5100 SERIES, 3.3 A, 18MM X 10MM X 24MM

Technical Specifications

Parameters and characteristics for this part

Part	Number of Lines	Package / Case	Package / Case	DC Resistance (DCR) (Max) [Max]	Filter Type	Height (Max)	Height (Max)	Current Rating (Max) [Max]	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]
Murata Power Solutions Inc. 51505C	2	4 Lead	Vertical	197 mOhm	Power Line	24 mm	0.945 in	1.2 A	Through Hole	125 °C	-40 °C	10 mm	18 mm	0.394 in	0.709 in
Murata Power Solutions Inc. 51305C	2	4 Lead	Vertical	97 mOhm	Power Line	24 mm	0.945 in	1.9 A	Through Hole	125 °C	-40 °C	10 mm	18 mm	0.394 in	0.709 in
Murata Power Solutions Inc. 51105C	2	4 Lead	Vertical	38 mOhm	Power Line	24 mm	0.945 in	3.3 A	Through Hole	125 °C	-40 °C	10 mm	18 mm	0.394 in	0.709 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 Line Common Mode Choke Through Hole 3.3A DCR 38mOhm
