VUO98-12NO7

Active

IXYS

BRIDGE RECT 3P 1.2KV ECO-PAC2

Search across all available documentation for this part.

Active

IXYS

BRIDGE RECT 3P 1.2KV ECO-PAC2

Technical Specifications

Parameters and characteristics for this part

Specification	VUO98-12NO7

Current - Average Rectified (Io)	100 A
Current - Reverse Leakage @ Vr	100 µA
Diode Type	Three Phase
Mounting Type	Chassis Mount
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-40 °C
Package / Case	ECO-PAC2
Supplier Device Package	ECO-PAC2
Technology	Standard
Voltage - Forward (Vf) (Max) @ If	1.14 V
Voltage - Peak Reverse (Max) [Max]	1.2 kV

Part	Mounting Type	Diode Type	Voltage - Peak Reverse (Max)	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Current - Reverse Leakage @ Vr	Technology	Current - Average Rectified (Io)	Supplier Device Package	Voltage - Forward (Vf) (Max) @ If	Voltage - Peak Reverse (Max) [Max]
IXYS VUO98-16NO7	Chassis Mount	Three Phase	1.6 kV	ECO-PAC2	150 °C	-40 °C	100 µA	Standard	105 A	ECO-PAC2	1.14 V
IXYS VUO98-12NO7	Chassis Mount	Three Phase		ECO-PAC2	150 °C	-40 °C	100 µA	Standard	100 A	ECO-PAC2	1.14 V	1.2 kV

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Bridge Rectifier Three Phase Standard 1.2 kV Chassis Mount ECO-PAC2
