DF20NA80F1

Active

SanRex Corporation

DIOE MODULE 800V 20A

Search across all available documentation for this part.

Active

SanRex Corporation

DIOE MODULE 800V 20A

Technical Specifications

Parameters and characteristics for this part

Part	Diode Type	Voltage - Peak Reverse (Max)	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Forward (Vf) (Max) @ If	Supplier Device Package	Package / Case	Technology	Mounting Type	Current - Reverse Leakage @ Vr	Voltage - Peak Reverse (Max) [Max]
SanRex Corporation DF20NA160 F1	Three Phase	1.6 kV	150 °C	-40 °C	1.2 V	5-SIP	5-SIP Exposed Pad	Standard	Through Hole	8 mA
SanRex Corporation DF20CA160	Three Phase	1.6 kV	150 °C	-40 °C	1.1 V		Module	Standard	Chassis Mount	8 mA
SanRex Corporation DF20AA120	Three Phase		150 °C	-40 °C	1.25 V		Module	Standard	Chassis Mount	3 mA	1.2 kV
SanRex Corporation DF20NA80F1	Three Phase		150 °C	-40 °C	1.2 V	5-SIP	5-SIP Exposed Pad	Standard	Through Hole	4 mA	800 V
SanRex Corporation DF20NA80S	Three Phase		150 °C	-40 °C	1.2 V	5-SIP	5-SIP Exposed Pad	Standard	Through Hole	4 mA	800 V
SanRex Corporation DF20NA160 S	Three Phase	1.6 kV	150 °C	-40 °C	1.2 V	5-SIP	5-SIP Exposed Pad	Standard	Through Hole	8 mA
SanRex Corporation DF20AA160	Three Phase	1.6 kV	150 °C	-40 °C	1.25 V		Module	Standard	Chassis Mount	3 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	81	$ 9.92

General part information

Bridge Rectifier Three Phase Standard 800 V Through Hole 5-SIP
