8A-03PFFS-SH7001

Active

Amphenol LTW

M SERIES SENSOR CONNECTOR, GUIDED M8, METAL, 3A, 03 PINS, FEMALE CONNECTOR, FEMALE CONTACT, HEXAGONAL, SCREW THREAD, SOLDER, REC

Search across all available documentation for this part.

Active

Amphenol LTW

M SERIES SENSOR CONNECTOR, GUIDED M8, METAL, 3A, 03 PINS, FEMALE CONNECTOR, FEMALE CONTACT, HEXAGONAL, SCREW THREAD, SOLDER, REC

Technical Specifications

Parameters and characteristics for this part

Specification	8A-03PFFS-SH7001

Color	Silver
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	3 A
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Rear Side Nut
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Zinc Alloy
Shell Size - Insert	M8-3
Shielding	Shielded
Voltage Rating	60 VDC

Part	Insert Material	Color	Contact Finish - Mating	Primary Material	Contact Material	Material Flammability Rating	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Orientation	Shell Finish	Ingress Protection	Mounting Feature	Voltage Rating	Connector Type	Shell Material	Shielding	Shell Size - Insert
Amphenol LTW 8A-03PFFS-SH7001	Polyamide (PA) Nylon Glass Filled	Silver	Gold	Metal	Copper Alloy	UL94 V-0	3 A	-40 °C	105 ░C	Keyed	Nickel	IP67 - Dust Tight Waterproof	Bulkhead - Rear Side Nut	60 VDC	Female Sockets Plug	Zinc Alloy	Shielded	M8-3

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Position Circular Connector Plug, Female Sockets Solder Cup
