TEC 3-4815

Active

Traco Power

DC DC CONVERTER 24V 3W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

TEC 3-4815

Active

Traco Power

DC DC CONVERTER 24V 3W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TEC 3-4815

Applications	ITE (Commercial)
Current - Output (Max) [Max]	125 mA
Efficiency	86 %
Features	Remote On/Off, SCP
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	90 °C
Operating Temperature [Min]	-40 °C
Package / Case	8-SIP Module
Package / Case	7 Leads
Power (Watts)	3 W
Size / Dimension [x]	0.86 in
Size / Dimension [x]	21.8 mm
Size / Dimension [y]	0.36 "
Size / Dimension [y]	9.1 mm
Size / Dimension [z]	11.2 mm
Size / Dimension [z]	0.44 "
Type	Isolated Module
Voltage - Input (Max) [Max]	75 V
Voltage - Input (Min) [Min]	36 V
Voltage - Isolation	1.6 kV
Voltage - Output 1	24 V

TEC 3 Series

Part	Current - Output (Max) [Max]	Efficiency	Number of Outputs	Voltage - Output 1	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Package / Case	Package / Case	Voltage - Input (Min) [Min]	Voltage - Isolation	Applications	Mounting Type	Power (Watts)	Features	Voltage - Input (Max) [Max]	Type	Current - Output (Max)	Current - Output (Max)	Voltage - Output 2	Current - Output (Max)
Traco Power TEC 3-4815	125 mA	86 %	1	24 V	-40 °C	90 °C	0.86 in	21.8 mm	11.2 mm	0.44 "	0.36 "	9.1 mm	8-SIP Module	7 Leads	36 V	1.6 kV	ITE (Commercial)	Through Hole	3 W	Remote On/Off SCP	75 V	Isolated Module
Traco Power TEC 3-4810	700 mA	75 %	1	3.3 V	-40 °C	90 °C	0.86 in	21.8 mm	11.2 mm	0.44 "	0.36 "	9.1 mm	8-SIP Module	7 Leads	36 V	1.6 kV	ITE (Commercial)	Through Hole	2.3 W	Remote On/Off SCP	75 V	Isolated Module
Traco Power TEC 3-0922			2	12 V	-40 °C	90 °C	0.86 in	21.8 mm	11.2 mm	0.44 "	0.36 "	9.1 mm	8-SIP Module	7 Leads	4.5 V	1.6 kV	ITE (Commercial)	Through Hole	3 W	Remote On/Off SCP	13.2 V	Isolated Module	125 mA	125 mA	-12 V
Traco Power TEC 3-1210WI	700 mA	75 %	1	3.3 V	-40 °C	90 °C	0.86 in	21.8 mm	11.2 mm	0.44 "	0.36 "	9.1 mm	8-SIP Module	7 Leads	4.5 V	1.6 kV	ITE (Commercial)	Through Hole	2.3 W	Remote On/Off SCP	18 V	Isolated Module
Traco Power TEC 3-0915	125 mA		1	24 V	-40 °C	90 °C	0.86 in	21.8 mm	11.2 mm	0.44 "	0.36 "	9.1 mm	8-SIP Module	7 Leads	4.5 V	1.6 kV	ITE (Commercial)	Through Hole	3 W	Remote On/Off SCP	13.2 V	Isolated Module
Traco Power TEC 3-2421WI		79 %	2	5 V	-40 °C	90 °C	0.86 in	21.8 mm	11.2 mm	0.44 "	0.36 "	9.1 mm	8-SIP Module	7 Leads	9 V	1.6 kV	ITE (Commercial)	Through Hole	3 W	Remote On/Off SCP	36 V	Isolated Module			-5 V	300 mA
Traco Power TEC 3-2419WI	333 mA	81 %	1	9 V	-40 °C	90 °C	0.86 in	21.8 mm	11.2 mm	0.44 "	0.36 "	9.1 mm	8-SIP Module	7 Leads	9 V	1.6 kV	ITE (Commercial)	Through Hole	3 W	Remote On/Off SCP	36 V	Isolated Module
Traco Power TEC 3-0919	333 mA	81 %	1	9 V	-40 °C	90 °C	0.86 in	21.8 mm	11.2 mm	0.44 "	0.36 "	9.1 mm	8-SIP Module	7 Leads	4.5 V	1.6 kV	ITE (Commercial)	Through Hole	3 W	Remote On/Off SCP	13.2 V	Isolated Module
Traco Power TEC 3-4821		80 %	2	5 V	-40 °C	90 °C	0.86 in	21.8 mm	11.2 mm	0.44 "	0.36 "	9.1 mm	8-SIP Module	7 Leads	36 V	1.6 kV	ITE (Commercial)	Through Hole	3 W	Remote On/Off SCP	75 V	Isolated Module			-5 V	300 mA
Traco Power TEC 3-2422		84 %	2	12 V	-40 °C	90 °C	0.86 in	21.8 mm	11.2 mm	0.44 "	0.36 "	9.1 mm	8-SIP Module	7 Leads	18 V	1.6 kV	ITE (Commercial)	Through Hole	3 W	Remote On/Off SCP	36 V	Isolated Module	125 mA	125 mA	-12 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 14.35
		10	$ 13.19
		25	$ 12.76
		50	$ 12.44
		100	$ 12.13
		250	$ 11.73
		500	$ 11.43

Description

General part information

TEC 3 Series

Isolated Module DC DC Converter 1 Output 24V 125mA 36V - 75V Input
