SKN.M04.GLLG

Active

LEMO

CONN RCPT FMALE 4P GOLD SLDR CUP

Search across all available documentation for this part.

Active

LEMO

CONN RCPT FMALE 4P GOLD SLDR CUP

Technical Specifications

Parameters and characteristics for this part

Specification	SKN.M04.GLLG

Applications	Medical, Industrial, Automotive, Testing Equipment & Measurement
Color	Gray
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Current Rating (Amps)	11.5 A
Fastening Type	Push-Pull
Ingress Protection	IP50
Insert Material	Polyetheretherketone (PEEK)
Mounting Feature	Front and Rear Side Nut
Number of Positions	4
Operating Temperature [Max]	170 °C
Operating Temperature [Min]	-50 °C
Orientation	N
Primary Material	Plastic
Shell Material	Sulfone
Shell Size - Insert	M04
Shielding	Unshielded

Part	Shell Size - Insert	Connector Type	Applications	Contact Finish - Mating	Shielding	Primary Material	Current Rating (Amps)	Color	Fastening Type	Insert Material	Mounting Feature	Number of Positions	Ingress Protection	Shell Material	Orientation	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Mounting Type
LEMO SKN.M06.GLLG	M06	Receptacle Female Sockets	Automotive Industrial Medical Testing Equipment & Measurement	Gold	Unshielded	Plastic	8.5 A	Gray	Push-Pull	Polyetheretherketone (PEEK)	Front and Rear Side Nut	6	IP50	Sulfone	N	-50 °C	170 °C
LEMO SKN.M04.GLLG	M04	Receptacle Female Sockets	Automotive Industrial Medical Testing Equipment & Measurement	Gold	Unshielded	Plastic	11.5 A	Gray	Push-Pull	Polyetheretherketone (PEEK)	Front and Rear Side Nut	4	IP50	Sulfone	N	-50 °C	170 °C
LEMO SKN.M08.GLLA	M08	Receptacle Female Sockets	Automotive Industrial Medical Testing Equipment & Measurement	Gold	Unshielded	Plastic	5 A	Blue Gray	Push-Pull	Polyetheretherketone (PEEK)	Front and Rear Side Nut	8	IP50	Sulfone	N	-50 °C	170 °C
LEMO SKN.M08.GLVG	M08	Receptacle Female Sockets	Automotive Industrial Medical Testing Equipment & Measurement	Gold	Unshielded	Plastic	5 A	Gray	Push-Pull	Polyetheretherketone (PEEK)	Front and Rear Side Nut	8	IP50	Sulfone	N	-50 °C	170 °C	Solder	Panel Mount Right Angle Through Hole
LEMO SKN.M04.BLLB	M04	Receptacle Female Sockets	Automotive Industrial Medical Testing Equipment & Measurement	Gold	Unshielded	Plastic	11.5 A	White	Push-Pull	Polyetheretherketone (PEEK)	Front and Rear Side Nut	4	IP50	Sulfone	N	-50 °C	170 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 Position Circular Connector Receptacle, Female Sockets Solder Cup

Technical documentation and resources
