SOB863860
ActiveCelduc Inc.
SSR RELAY SPST-NO 35A 24-600V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SOB863860
ActiveCelduc Inc.
SSR RELAY SPST-NO 35A 24-600V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SOB863860 |
|---|---|
| Approval Agency | CE |
| Load Current | 35 A |
| Mounting Type | Chassis Mount |
| On-State Resistance (Max) [Max] | 9.5 mOhms |
| Operating Temperature [Max] | 90 °C |
| Operating Temperature [Min] | -40 °C |
| Output Type | AC, Zero Cross |
| Package / Case | Module |
| Termination Style | Screw Terminal |
| Voltage - Input | 24VAC/DC |
| Voltage - Load [Max] | 600 V |
| Voltage - Load [Min] | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 152.86 | |
Description
General part information
SOB863 Series
Solid State SPST-NO (1 Form A) Module
Documents
Technical documentation and resources
