TI900-150-150-0.12-0

Active

t-Global Technology

THERM PAD 150MMX150MM WHT

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Die-Cut Tolerence Guide +2

TI900-150-150-0.12-0

Active

t-Global Technology

THERM PAD 150MMX150MM WHT

Deep-Dive with AI

DocumentsDatasheet Die-Cut Tolerence Guide +2

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TI900-150-150-0.12-0

Backing, Carrier	Viscose
Color	White
Material	Silicone
Outline [x]	150 mm
Outline [y]	150 mm
Shape	Square
Shelf Life	24 Months
Thermal Conductivity	1.8 W/m-K
Thickness [x]	0.005 in
Thickness [x]	0.127 mm
Type	Conductive Insulator Pad

TI900 Series

Part	Backing, Carrier	Material	Thickness [x]	Thickness [x]	Shape	Shelf Life	Color	Thermal Conductivity	Type	Outline [y]	Outline [x]	Adhesive
t-Global Technology TI900-20-10-0.12-0	Viscose	Silicone	0.005 in	0.127 mm	Rectangular	24 Months	White	1.8 W/m-K	Conductive Insulator Pad	10 mm	20 mm
t-Global Technology TI900-10-50-0.12-0	Viscose	Silicone	0.005 in	0.127 mm	Rectangular	24 Months	White	1.8 W/m-K	Conductive Insulator Pad	10 mm	50 mm
t-Global Technology TI900-50M-320-0.12-0	Viscose	Silicone	0.005 in	0.127 mm	Rectangular	24 Months	White	1.8 W/m-K	Conductive Insulator Pad Roll	320 mm	50 m
t-Global Technology TI900-25-25-0.12-0	Viscose	Silicone	0.005 in	0.127 mm	Square	24 Months	White	1.8 W/m-K	Conductive Insulator Pad	25 mm	25 mm
t-Global Technology TI900-5-5-0.12-0	Viscose	Silicone	0.005 in	0.127 mm	Square	24 Months	White	1.8 W/m-K	Conductive Insulator Pad	5 mm	5 mm
t-Global Technology TI900-144.4-38-0.12-0	Viscose	Silicone	0.005 in	0.127 mm	Rectangular	24 Months	White	1.8 W/m-K	Conductive Insulator Pad	38 mm	144.4 mm
t-Global Technology TI900-105-37-0.12-0	Viscose	Silicone	0.005 in	0.127 mm	Rectangular	24 Months	White	1.8 W/m-K	Conductive Insulator Pad	37 mm	105 mm
t-Global Technology TI900-105-27-0.12-0	Viscose	Silicone	0.005 in	0.127 mm	Rectangular	24 Months	White	1.8 W/m-K	Conductive Insulator Pad	27 mm	105 mm	Adhesive - One Side
t-Global Technology TI900-150-150-0.12-0	Viscose	Silicone	0.005 in	0.127 mm	Square	24 Months	White	1.8 W/m-K	Conductive Insulator Pad	150 mm	150 mm
t-Global Technology TI900-30-30-0.12-0	Viscose	Silicone	0.005 in	0.127 mm	Square	24 Months	White	1.8 W/m-K	Conductive Insulator Pad	30 mm	30 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 14.09
		10	$ 12.50
		25	$ 11.92
		50	$ 11.50
		100	$ 11.09
		250	$ 10.57
		500	$ 10.20
		1000	$ 9.83
