20LPCV2440

Obsolete

Sensata-Crydom

SSR RELAY SPST-NO 40A 20-300V

Search across all available documentation for this part.

Obsolete

Sensata-Crydom

SSR RELAY SPST-NO 40A 20-300V

Technical Specifications

Parameters and characteristics for this part

Specification	20LPCV2440

Approval Agency	CE
Load Current	40 A
Mounting Type	Chassis Mount
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-30 ░C
Output Type	AC, Proportional Control
Package / Case	Module
Termination Style	Screw Terminal, Quick Connect
Termination Style	0.25 in
Voltage - Input [Max]	20 mA
Voltage - Input [Min]	4 mA
Voltage - Load [Max]	300 V
Voltage - Load [Min]	20 V

Part	Voltage - Input [Min]	Voltage - Input [Max]	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Output Type	Approval Agency	Mounting Type	Voltage - Load [Max]	Voltage - Load [Min]	Termination Style	Termination Style	Load Current
Sensata-Crydom 20LPCV2440	4 mA	20 mA	Module	-30 ░C	80 C	AC Proportional Control	CE	Chassis Mount	300 V	20 V	Quick Connect Screw Terminal	0.25 in	40 A
Sensata-Crydom 20LPCV2415	4 mA	20 mA	Module	-30 ░C	80 C	AC Proportional Control	CE	Chassis Mount	300 V	20 V	Quick Connect Screw Terminal	0.25 in	15 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Solid State SPST-NO (1 Form A) Module
