ABP2MDAN004ND2B3XX

Active

Honeywell Sensing and Productivity Solutions

SENSOR 0.11" 14BIT 6SMD

Search across all available documentation for this part.

Active

Honeywell Sensing and Productivity Solutions

SENSOR 0.11" 14BIT 6SMD

Technical Specifications

Parameters and characteristics for this part

Specification	ABP2MDAN004ND2B3XX

Accuracy	0.25 %
Features	Temperature Compensated, Amplified Output
Mounting Type	Surface Mount
Operating Temperature [Max]	110 °C
Operating Temperature [Min]	-40 °C
Output	14 b
Output Type	I2C
Package / Case	Dual Ports, J-Lead, 6-SMD, Same Side
Port Size	0.11 ", 2.74 mm
Port Style	Barbed
Pressure Type	Vented Gauge
Supplier Device Package	6-SMD
Termination Style	J Lead
Voltage - Supply [Max]	3.6 V
Voltage - Supply [Min]	1.8 V

Part	Voltage - Supply [Max]	Voltage - Supply [Min]	Package / Case	Output Type	Port Style	Accuracy	Output	Mounting Type	Termination Style	Features	Pressure Type	Port Size	Supplier Device Package	Operating Temperature [Min]	Operating Temperature [Max]
Honeywell Sensing and Productivity Solutions ABP2MDAN004ND2B3XX	3.6 V	1.8 V	6-SMD Dual Ports J-Lead Same Side	I2C	Barbed	0.25 %	14 b	Surface Mount	J Lead	Amplified Output Temperature Compensated	Vented Gauge	0.11 " 2.74 mm	6-SMD	-40 °C	110 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pressure Sensor Vented Gauge Male - 0.11" (2.74mm) Tube 14 b 6-SMD, J-Lead, Dual Ports, Same Side
