047-12SMPSM+
ActiveMINI-CIRCUITS
CBL ASSY SMA-SMP PLUG-JACK 12"
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
047-12SMPSM+
ActiveMINI-CIRCUITS
CBL ASSY SMA-SMP PLUG-JACK 12"
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 047-12SMPSM+ |
|---|---|
| 1st Connector | SMA Plug |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 1st Contact Gender | Male |
| 2nd Connector | SMP Jack |
| 2nd Connector Mounting Type | Free Hanging (In-Line) |
| 2nd Contact Gender | Female |
| Cable Type | Hand Formable .047 |
| Color | Blue |
| Frequency - Max [Max] | 18 GHz |
| Length | 12 " |
| Length | 304.8 mm |
| Overall Impedance | 50 Ohms |
| Style | SMA to SMP |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 43.55 | |
Description
General part information
047-12 Series
Cable Assembly Coaxial SMA to SMP Hand Formable .047 12.00" (304.80mm)
