2D1.6UM
ActiveTE Connectivity Raychem Cable Protection
CIR BRKR THRM-MAG 1.6A LEVER
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 2D1.6UM |
|---|---|
| Actuator Type | Lever |
| Approval Agency | CSA, UL508, VDE |
| Breaker Type | Thermal Magnetic |
| Current Rating (Amps) | 1.6 A |
| Illumination | None |
| Mounting Type | DIN Rail |
| Number of Poles | 2 |
| Voltage Rating - AC | 480 V |
| Voltage Rating - DC | 80 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 44.50 | |
| 5 | $ 37.06 | |||
| 10 | $ 34.24 | |||
| 50 | $ 28.46 | |||
| 100 | $ 26.25 | |||
| 250 | $ 23.58 | |||
Description
General part information
2D1.6 Series
Circuit Breaker Thermal Magnetic 1.6A 480 V AC 80 V DC Lever DIN Rail
