5-1414968-1
ActiveTE Connectivity Potter & Brumfield Relays
V23132B2002B200-EV-USBX
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
5-1414968-1
ActiveTE Connectivity Potter & Brumfield Relays
V23132B2002B200-EV-USBX
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 5-1414968-1 |
|---|---|
| Coil Current | 170.2 mA |
| Coil Resistance | 141 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 24 VDC |
| Contact Form | SPST-NO (DM) (1 Form X) |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Contact Rating (Current) | 130 A |
| Mounting Type | Chassis Mount |
| Must Operate Voltage | 14.4 VDC |
| Must Release Voltage | 2.4 VDC |
| Operate Time | 25 ms |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Relay Type | General Purpose |
| Release Time | 8 ms |
| Switching Voltage | 24 VDC |
| Termination Style | Screw Terminal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 104.07 | |
| 50 | $ 86.73 | |||
| 100 | $ 80.95 | |||
Description
General part information
V23132 Series
General Purpose Relay SPST-NO (DM) (1 Form X) 24VDC Coil Chassis Mount
Documents
Technical documentation and resources
