110IMY70-12-0TG

Active

EOS Power India Private Ltd

DC DC CONVERTER 12V 90W

Search across all available documentation for this part.

Active

EOS Power India Private Ltd

DC DC CONVERTER 12V 90W

Technical Specifications

Parameters and characteristics for this part

Specification	110IMY70-12-0TG

Applications	Railway, ITE (Commercial)
Current - Output (Max) [Max]	7.5 A
Efficiency	93 %
Features	OTP, SCP, OCP
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	203 °F
Operating Temperature [Min]	-40 °C
Package / Case	19-DIP Module
Power (Watts)	90 W
Size / Dimension [x]	3 "
Size / Dimension [x]	76.2 mm
Size / Dimension [y]	2.5 in
Size / Dimension [y]	63.5 mm
Size / Dimension [z]	0.49 in
Size / Dimension [z]	12.5 mm
Type	Isolated Module, Conformal Coated
Voltage - Input (Max) [Max]	137.5 V
Voltage - Input (Min) [Min]	50 V
Voltage - Isolation	4.2 kV
Voltage - Output 1	12 V

Part	Current - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Features	Power (Watts)	Voltage - Input (Max) [Max]	Type	Control Features	Voltage - Output 1	Voltage - Input (Min) [Min]	Applications	Voltage - Isolation	Package / Case	Mounting Type	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Efficiency	Number of Outputs
EOS Power India Private Ltd 110IMY70-15-0ITZG	6 A	-40 °C	203 °F	OCP OTP OVP Remote On/Off SCP UVLO	90 W	137.5 V	Conformal Coated Isolated Module	Active High Enable	15 V	50 V	ITE (Commercial) Railway	4.2 kV	19-DIP Module 17 Leads	Through Hole	0.38 in	9.8 mm	2.87 in	47.8 mm	1.88 "	72.8 mm	93 %	1
EOS Power India Private Ltd 110IMY70-12-0TG	7.5 A	-40 °C	203 °F	OCP OTP SCP	90 W	137.5 V	Conformal Coated Isolated Module		12 V	50 V	ITE (Commercial) Railway	4.2 kV	19-DIP Module	Through Hole	0.49 in	12.5 mm	3 "	63.5 mm	2.5 in	76.2 mm	93 %	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	60	$ 231.79

General part information

Isolated Module, Conformal Coated DC DC Converter 1 Output 12V 7.5A 50V - 137.5V Input

Technical documentation and resources

No documents available
