XT40.481

Active

PULS, LP

AC/DC DIN RAIL SUPPLY 48V 960W

Search across all available documentation for this part.

Active

PULS, LP

AC/DC DIN RAIL SUPPLY 48V 960W

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Isolation	Power (Watts)	Applications	Current - Output (Max) [Max]	Voltage - Output 1	Features	Operating Temperature [Min]	Operating Temperature [Max]	Efficiency	AC Voltage - Input [Min]	AC Voltage - Input [Max]	Number of Outputs	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Input Type	Approval Agency	Standard Number
PULS, LP XT40.241	500 V	960 W	Industrial ITE (Commercial)	40 A	24 V	IP20 PFC	-25 °C	70 °C	95.5 %	300 VAC	460 VAC	1	96 mm	157 mm	124 mm	6.18 "	3.78 in	4.88 "	AC	EAC IEC UL	508 60950-1 61010-2-201
PULS, LP XT40.362	3000 V	960 W	ITE (Commercial)	26 A	36 V	IP20	-25 °C	70 °C	95.5 %	360 VAC	552 VAC	1	96 mm	157 mm	124 mm	6.18 "	3.78 in	4.88 "	AC	EAC IEC UL	508 60950-1 61010-2-201
PULS, LP XT40.361	500 V	958 W	Industrial ITE (Commercial)	26.6 A	36 V	IP20 PFC	-25 °C	70 °C	95.5 %	300 VAC	460 VAC	1	96 mm	157 mm	124 mm	6.18 "	3.78 in	4.88 "	AC	EAC IEC UL	508 60950-1 61010-2-201
PULS, LP XT40.481	3000 V	960 W	ITE (Commercial)	20 A	48 V	IP20	-25 °C	70 °C	96 %	300 VAC	460 VAC	1	96 mm	157 mm	124 mm	6.18 "	3.78 in	4.88 "	AC	EAC IEC UL	508 60950-1 61010-2-201
PULS, LP XT40.482	3000 V	960 W	ITE (Commercial)	20 A	48 V	IP20	-25 °C	70 °C	96 %	360 VAC	552 VAC	1	96 mm	157 mm	124 mm	6.18 "	3.78 in	4.88 "	AC	EAC IEC UL	508 60950-1 61010-2-201
PULS, LP XT40.721	3000 V	960 W	ITE (Commercial)	13 A	72 V	IP20	-25 °C	70 °C	95.5 %	300 VAC	460 VAC	1	96 mm	157 mm	124 mm	6.18 "	3.78 in	4.88 "	AC	EAC IEC UL	508 60950-1 61010-2-201

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 711.00

General part information

AC/DC DIN RAIL SUPPLY 48V 960W

Technical documentation and resources
