AM2GH-2403SZ
ActiveDComponents
DC DC CONVERTER 3.3V 1.7W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AM2GH-2403SZ
ActiveDComponents
DC DC CONVERTER 3.3V 1.7W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AM2GH-2403SZ |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output (Max) [Max] | 500 mA |
| Efficiency | 71 % |
| Features | Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 8-SIP Module |
| Power (Watts) | 2 W |
| Size / Dimension [x] | 21.9 mm |
| Size / Dimension [x] | 0.86 in |
| Size / Dimension [y] | 9.2 mm |
| Size / Dimension [y] | 0.36 " |
| Size / Dimension [z] | 0.44 " |
| Size / Dimension [z] | 11.1 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 9 V |
| Voltage - Isolation | 1.6 kV |
| Voltage - Output 1 | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 17.65 | |
| 10 | $ 15.51 | |||
| 25 | $ 14.74 | |||
| 50 | $ 14.17 | |||
| 100 | $ 13.63 | |||
| 250 | $ 12.95 | |||
| 500 | $ 12.46 | |||
Description
General part information
AM2GH Series
Isolated Module DC DC Converter 1 Output 3.3V 500mA 9V - 36V Input
