Technical Specifications
Parameters and characteristics for this part
| Specification | 904-00933 |
|---|---|
| Abrasion Protection | Abrasion Resistant |
| Color | Black |
| Diameter - Inside [diameter] | 1.257 " |
| Diameter - Inside [diameter] | 31.93 mm |
| Diameter - Outside [diameter] | 38.1 mm |
| Diameter - Outside [diameter] | 1.5 in |
| Environment Protection | UV Resistant, Weather Resistant |
| Length | 548.64 m |
| Length | 1800 ft |
| Material | Polyethylene (PE) |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Type | Protective Hose, Wire Loom |
| Type Attributes | Convoluted, Corrugated |
| Wall Thickness | 0.15 mm |
| Wall Thickness | 0.006 in |
H-Mount Series
Screwdrivers, Nut Drivers & Socket Drivers HBIT
| Part | Diameter - Inside [diameter] | Diameter - Inside [diameter] | Environment Protection | Length | Length | Diameter - Outside [diameter] | Diameter - Outside [diameter] | Wall Thickness | Wall Thickness | Type | Operating Temperature [Max] | Operating Temperature [Min] | Abrasion Protection | Material | Color | Type Attributes | Drive Size | Tip Type | Tool Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
HELLERMANNTYTON | 1.257 " | 31.93 mm | UV Resistant Weather Resistant | 548.64 m | 1800 ft | 38.1 mm | 1.5 in | 0.15 mm | 0.006 in | Protective Hose Wire Loom | 85 °C | -40 °C | Abrasion Resistant | Polyethylene (PE) | Black | Convoluted Corrugated | |||
HELLERMANNTYTON | 0.25 " | Drill Bit | Bit Insert |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
H-Mount Series
Screwdrivers, Nut Drivers & Socket Drivers HBIT
Documents
Technical documentation and resources
