MOV07V300Y-AP
ActiveEaton - Electronics Division
VARISTOR 300 VAC 7MM DISC
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MOV07V300Y-AP
ActiveEaton - Electronics Division
VARISTOR 300 VAC 7MM DISC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MOV07V300Y-AP |
|---|---|
| Capacitance @ Frequency | 105 pF |
| Current - Surge | 1.2 kA |
| Energy | 29 J |
| Maximum AC Volts | 300 V |
| Maximum DC Volts [Max] | 385 V |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Disc |
| Package / Case [diameter] | 7 mm |
| Varistor Voltage (Max) [Max] | 517 V |
| Varistor Voltage (Min) [Min] | 423 V |
| Varistor Voltage (Typ) | 470 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Box (TB) | 1250 | $ 0.08 | |
Description
General part information
MOV07 Series
470 V 1.2 kA Varistor 1 Circuit Through Hole Disc 7mm
