37112C

Active

Murata Power Solutions Inc.

POWER INDUCTOR (SMD), 1.1 ΜH, 14.5 A, UNSHIELDED, 20 A, 3700 SERIES

Search across all available documentation for this part.

Active

Murata Power Solutions Inc.

POWER INDUCTOR (SMD), 1.1 ΜH, 14.5 A, UNSHIELDED, 20 A, 3700 SERIES

Technical Specifications

Parameters and characteristics for this part

Power Inductors - SMD 2.4 UH 12A

Part	Current Rating (Amps)	Inductance	Current - Saturation (Isat)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Shielding	Mounting Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Inductance Frequency - Test	Operating Temperature [Min]	Operating Temperature [Max]	DC Resistance (DCR) [Max]	Type	Tolerance	Package / Case	DC Resistance (DCR)
Murata Power Solutions Inc. 37242C	12 A	2.4 µH	16.5 A	6.8 mm	0.268 in	Unshielded	Surface Mount	11.5 mm	0.571 in	0.453 in	14.5 mm	100 kHz	-40 °C	130 °C	3 mOhm	Wirewound	10 %	Nonstandard
Murata Power Solutions Inc. 37112C	14.5 A	1.1 µH	20 A	5.8 mm	0.228 "	Unshielded	Surface Mount	11.5 mm	0.571 in	0.453 in	14.5 mm	100 kHz	-40 °C	130 °C	2.2 mOhm	Wirewound	10 %	Nonstandard
Murata Power Solutions Inc. 37301C	19.5 A	300 nH	39 A	5.8 mm	0.228 "	Unshielded	Surface Mount	11.5 mm	0.571 in	0.453 in	14.5 mm	100 kHz	-40 °C	130 °C		Wirewound	20 %	Nonstandard	0.9 mOhm
Murata Power Solutions Inc. 37392C	10 A	3.9 µH		6.8 mm	0.268 in	Unshielded	Surface Mount	11.5 mm	0.571 in	0.453 in	14.5 mm	100 kHz	-40 °C	130 °C	4.2 mOhm	Wirewound	10 %	Nonstandard
Murata Power Solutions Inc. 37951C	18 A	950 nH		6.8 mm	0.268 in	Unshielded	Surface Mount	11.5 mm	0.571 in	0.453 in	14.5 mm	100 kHz	-40 °C	130 °C	1.3 mOhm	Wirewound	20 %	Nonstandard

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Retail Package	100	$ 1.55
	Tape & Reel (TR)	700	$ 1.33
Newark	Each (Supplied on Cut Tape)	1	$ 1.53

General part information

Power Inductors - SMD 2.4 UH 12A
