SRU6025A-330Y

Active

Bourns Inc.

IND6.2X6.5X2.5MM,33UH30%1.2A,SHDSMD /TAPE & REEL - 7" REEL

Search across all available documentation for this part.

Active

Bourns Inc.

IND6.2X6.5X2.5MM,33UH30%1.2A,SHDSMD /TAPE & REEL - 7" REEL

Technical Specifications

Parameters and characteristics for this part

Part	Q @ Freq	Inductance Frequency - Test	Operating Temperature [Max]	Operating Temperature [Min]	Material - Core	Current - Saturation (Isat)	Inductance	Package / Case	Frequency - Self Resonant	Current Rating (Amps)	Ratings	Shielding	Type	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Tolerance	DC Resistance (DCR)	Mounting Type	DC Resistance (DCR) [Max]
Bourns Inc. SRU6025A-1R2Y	7.96 MHz 8	100 kHz	125 °C	-40 °C	Ferrite	3.2 A	1.2 µH	Nonstandard	120 MHz	4 A	AEC-Q200	Shielded	Drum Core Wirewound	0.256 "	6.5 mm	6.2 mm	0.244 in	30 %	19 mOhm	Surface Mount
Bourns Inc. SRU6025A-330Y	2.52 MHz 12	100 kHz	125 °C	-40 °C	Ferrite	640 mA	33 µH	Nonstandard	12 MHz	1.2 A	AEC-Q200	Shielded	Drum Core Wirewound	0.256 "	6.5 mm	6.2 mm	0.244 in	30 %	180 mOhm	Surface Mount
Bourns Inc. SRU6025A-2R2Y	7.96 MHz 8	100 kHz	125 °C	-40 °C	Ferrite	2.35 A	2.2 µH	Nonstandard	65 MHz	3.4 A	AEC-Q200	Shielded	Drum Core Wirewound	0.256 "	6.5 mm	6.2 mm	0.244 in	30 %		Surface Mount	24 mOhm
Bourns Inc. SRU6025A-221Y	20 796 kHz	100 kHz	125 °C	-40 °C	Ferrite	240 mA	220 µH	Nonstandard	4 MHz	0.42 A	AEC-Q200	Shielded	Drum Core Wirewound	0.256 "	6.5 mm	6.2 mm	0.244 in	30 %		Surface Mount	1.25 Ohm
Bourns Inc. SRU6025A-151Y	30 796 kHz	100 kHz	125 °C	-40 °C	Ferrite	280 mA	150 µH	Nonstandard	5 MHz	0.54 A	AEC-Q200	Shielded	Drum Core Wirewound	0.256 "	6.5 mm	6.2 mm	0.244 in	30 %		Surface Mount	770 mOhm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 0.99
	Digi-Reel®	1	$ 0.99
	Tape & Reel (TR)	2400	$ 0.46
Newark	Each (Supplied on Cut Tape)	500	$ 0.59

General part information

33 µH Shielded Drum Core, Wirewound Inductor 1.2 A 180mOhm Max Nonstandard
