UF220APA12-H2C2A-B1

Active

Mechatronics Bearing Group

FAN IMP 223X71MM 115VAC TACH

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsAC Axial Part Numbering Guide Datasheet +1

UF220APA12-H2C2A-B1

Active

Mechatronics Bearing Group

FAN IMP 223X71MM 115VAC TACH

Deep-Dive with AI

DocumentsAC Axial Part Numbering Guide Datasheet +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	UF220APA12-H2C2A-B1

Air Flow	530 CFM
Air Flow	14.84 mł/min
Approval Agency	CE, cUL, TUV, UL
Bearing Type	Ball
Current Rating (Amps)	800 mA
Fan Type	Motorized Impellers
Features	Speed Sensor (Tach), Thermal Overload Protector (TOP), Permanent Split Capacitor Motor
Material - Blade	Polyamide (PA), Nylon
Material - Frame	Aluminum
Noise	70 dB(A)
Operating Temperature [Max]	50 °C
Operating Temperature [Max]	50 °C
Operating Temperature [Min]	-40 °C
Operating Temperature [Min]	-40 °C
Power (Watts)	117 W
RPM	2650 RPM
Size / Dimension [diameter]	223 mm
Static Pressure	423.5 Pa
Static Pressure	1.7 in H2O
Termination	4 Wire Leads
Voltage - Rated	115 VAC
Weight	3.2 lbs
Weight	1.5 kg
Width [x]	71 mm

UF220 Series

Part	Termination	Static Pressure	Static Pressure	Approval Agency	Air Flow	Air Flow	Noise	Width [x]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [diameter]	Power (Watts)	Voltage - Rated	Bearing Type	Features	Current Rating (Amps)	Material - Blade	RPM	Fan Type	Material - Frame	Weight	Weight	Width [y]
Mechatronics Bearing Group UF220APA12-H2C2A-B1	4 Wire Leads	423.5 Pa	1.7 in H2O	CE cUL TUV UL	530 CFM	14.84 mł/min	70 dB(A)	71 mm	50 °C	-40 °C	-40 °C	50 °C	223 mm	117 W	115 VAC	Ball	Permanent Split Capacitor Motor Speed Sensor (Tach) Thermal Overload Protector (TOP)	800 mA	Nylon Polyamide (PA)	2650 RPM	Motorized Impellers	Aluminum	3.2 lbs	1.5 kg
Mechatronics Bearing Group UF220APA12-H2C2A	4 Wire Leads	423.5 Pa	1.7 in H2O	CE cUL TUV UL	530 CFM	14.84 mł/min	70 dB(A)	71 mm	50 °C	-40 °C	-40 °C	50 °C	223 mm	117 W	115 VAC	Ball	Permanent Split Capacitor Motor Thermal Overload Protector (TOP)	800 mA	Nylon Polyamide (PA)	2650 RPM	Motorized Impellers	Aluminum	3.2 lbs	1.5 kg
Mechatronics Bearing Group UF220APA12-H2C2F	4 Wire Leads	423.5 Pa	1.7 in H2O	CE cUL TUV UL	434 CFM	12.15 m³/min	65 dB		50 °C	-40 °C	-40 °C	50 °C	259 mm	117 W	115 VAC	Ball	Permanent Split Capacitor Motor Thermal Overload Protector (TOP)	800 mA	Nylon Polyamide (PA)	2650 RPM	Motorized Impellers	Aluminum	4.1 lbs	1.9 kg	97.8 mm
Mechatronics Bearing Group UF220APA23-H2C2A	4 Wire Leads	423.5 Pa	1.7 in H2O	CE cUL TUV UL	530 CFM	14.84 mł/min	70 dB(A)	71 mm	50 °C	-40 °C	-40 °C	50 °C	223 mm	117 W	230 VAC	Ball	Permanent Split Capacitor Motor Thermal Overload Protector (TOP)	390 mA	Nylon Polyamide (PA)	2650 RPM	Motorized Impellers	Aluminum	3.2 lbs	1.5 kg

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 92.19

Description

General part information

UF220 Series

Fan Motorized Impellers 115VAC Round - 223mm Dia Ball 530.0 CFM (14.84m³/min) 4 Wire Leads

Documents

Technical documentation and resources

AC Axial Part Numbering Guide

Datasheet

Blowers & Impellers Part Numbering

Datasheet
