GCLP37M37F

Active

MH Connectors

D SUB CONNECTOR ADAPTER, STANDARD D SUB, PLUG, 37 POSITIONS, STANDARD D SUB, RECEPTACLE

Search across all available documentation for this part.

Active

MH Connectors

D SUB CONNECTOR ADAPTER, STANDARD D SUB, PLUG, 37 POSITIONS, STANDARD D SUB, RECEPTACLE

Technical Specifications

Parameters and characteristics for this part

Specification	GCLP37M37F

Connector Style	Connector Saver
Contact Finish	Gold
Contact Finish Thickness	Flash
Convert From (Adapter End)	D-Sub, 37 Pin Male
Convert To (Adapter End)	D-Sub, 37 Pin Female
Current Rating (Amps)	5 A
Housing Color	Yellow
Includes	1 Connector, 2 Jack Screws
Material Flammability Rating	UL94 V-0
Number of Rows	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C

Part	Contact Finish	Current Rating (Amps)	Number of Rows	Housing Color	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish Thickness	Convert From (Adapter End)	Includes	Convert To (Adapter End)	Connector Style	Material Flammability Rating
MH Connectors GCLP37M37F	Gold	5 A	2	Yellow	105 ░C	-55 °C	Flash	D-Sub 37 Pin Male	1 Connector 2 Jack Screws	37 Pin Female D-Sub	Connector Saver	UL94 V-0

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Adapter Connector D-Sub, 37 Pin Female To D-Sub, 37 Pin Male Panel Mount
