39.11.0.012.0060

Active

Finder Relays, Inc.

RELAY GEN PURPOSE SPDT 6A 12V

Search across all available documentation for this part.

Active

Finder Relays, Inc.

RELAY GEN PURPOSE SPDT 6A 12V

Technical Specifications

Parameters and characteristics for this part

Part	Release Time	Relay Type	Must Release Voltage	Coil Type	Switching Voltage [Max]	Operate Time	Contact Material	Coil Voltage	Operating Temperature [Min]	Operating Temperature [Max]	Load - Max Switching [Max]	Contact Form	Termination Style	Must Operate Voltage	Approval Agency	Mounting Type	Coil Resistance	Contact Rating (Current)	Coil Current
Finder Relays, Inc. 39.11.0.125.0073	6 ms	General Purpose	12.5 VAC/DC	Non Latching	400 VAC	5 ms	Silver Nickel (AgNi)	125 VAC/DC	-40 °C	70 °C	2400 VA	SPDT (1 Form C)	Screw Terminal	88 VAC/DC	CE CSA cURus EAC RINA VDE	DIN Rail	22.3 kOhms	6 A
Finder Relays, Inc. 39.11.0.012.0060	6 ms	General Purpose	1.5 VAC/DC	Non Latching	400 VAC	5 ms	Silver Nickel (AgNi)	12 VAC/DC	-40 °C	70 °C	2400 VA	SPDT (1 Form C)	Screw Terminal	9.6 VAC/DC	CE CSA cURus EAC RINA VDE	DIN Rail	800 Ohms	6 A	15 mA
Finder Relays, Inc. 39.11.0.006.0060	6 ms	General Purpose	0.6 VAC/DC	Non Latching	400 VAC	5 ms	Silver Nickel (AgNi)	6 VAC	-40 °C	70 °C	2400 VA	SPDT (1 Form C)	Screw Terminal	4.8 VAC/DC	CE CSA cURus EAC RINA VDE	DIN Rail	171.4 Ohms	6 A	35 mA
Finder Relays, Inc. 39.11.0.024.0060	6 ms	General Purpose	2.4 VAC/DC	Non Latching	400 VAC	5 ms	Silver Nickel (AgNi)	24 VAC	-40 °C	70 °C	2400 VA	SPDT (1 Form C)	Screw Terminal	19.2 VAC	CE CSA cURus EAC RINA VDE	DIN Rail	2.2 kOhms	6 A	11 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay SPDT (1 Form C) 12VAC/DC Coil DIN Rail
