SRU5016-220Y

Active

Bourns Inc.

IND5.2X5.2X1.6MM,22UH30%0.65A,SHDSMD /TAPE & REEL - 7" REEL ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

Bourns Inc.

IND5.2X5.2X1.6MM,22UH30%0.65A,SHDSMD /TAPE & REEL - 7" REEL ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Part	Q @ Freq	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Frequency - Self Resonant	Mounting Type	DC Resistance (DCR)	Package / Case	Tolerance	Material - Core	Inductance	Current Rating (Amps)	Inductance Frequency - Test	Current - Saturation (Isat)	Type	Shielding	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]
Bourns Inc. SRU5016-100Y	2.52 MHz 15	0.205 "	5.2 mm	0.205 in	5.2 mm	40 MHz	Surface Mount	84 mOhm	Nonstandard	30 %	Ferrite	10 µH	1 A	100 kHz	900 mA	Drum Core Wirewound	Shielded	0.071 "	1.8 mm	125 °C	-40 °C
Bourns Inc. SRU5016-6R8Y	7.96 MHz 8	0.205 "	5.2 mm	0.205 in	5.2 mm	50 MHz	Surface Mount	50 mOhm	Nonstandard	30 %	Ferrite	6.8 µH	1.2 A	100 kHz	1.1 A	Drum Core Wirewound	Shielded	0.071 "	1.8 mm	125 °C	-40 °C
Bourns Inc. SRU5016-1R0Y		0.205 "	5.2 mm	0.205 in	5.2 mm		Surface Mount		Nonstandard	30 %	Ferrite	1 µH		100 kHz		Drum Core Wirewound	Shielded	0.071 "	1.8 mm	125 °C	-40 °C
Bourns Inc. SRU5016-680Y	2.52 MHz 18	0.205 "	5.2 mm	0.205 in	5.2 mm	15 MHz	Surface Mount	560 mOhm	Nonstandard	30 %	Ferrite	68 µH	360 mA	100 kHz		Drum Core Wirewound	Shielded	0.071 "	1.8 mm	125 °C	-40 °C
Bourns Inc. SRU5016-220Y	2.52 MHz 15	0.205 "	5.2 mm	0.205 in	5.2 mm	28 MHz	Surface Mount	195 mOhm	Nonstandard	30 %	Ferrite	22 µH	650 mA	100 kHz	560 mA	Drum Core Wirewound	Shielded	0.071 "	1.8 mm	125 °C	-40 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

22 µH Shielded Drum Core, Wirewound Inductor 650 mA 195mOhm Nonstandard
