3403.0122.11

Active

SCHURTER Inc.

FUSE: FUSE; 4A; 125VAC; 125VDC; TIME-LAG; CERAMIC; 11X4.6X3.9MM; SMD

Search across all available documentation for this part.

Active

SCHURTER Inc.

FUSE: FUSE; 4A; 125VAC; 125VDC; TIME-LAG; CERAMIC; 11X4.6X3.9MM; SMD

Technical Specifications

Parameters and characteristics for this part

Specification	3403.0122.11

Breaking Capacity @ Rated Voltage	100 A
Current Rating (Amps)	4 A
Fuse Type	Board Mount
Melting I˛t	23
Mounting Type	Surface Mount
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	2-SMD, J-Lead
Response Time	Slow Blow
Size / Dimension [x]	0.433 in
Size / Dimension [x]	11 mm
Size / Dimension [y]	4.6 mm
Size / Dimension [y]	0.181 in
Size / Dimension [z]	3.9 mm
Size / Dimension [z]	0.154 in
Voltage Rating - AC	125 V

Part	Voltage Rating - AC	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Fuse Type	Package / Case	Current Rating (Amps)	Response Time	Approval Agency	Breaking Capacity @ Rated Voltage	Mounting Type	Melting I˛t	Voltage Rating - DC	Operating Temperature [Max]	Operating Temperature [Min]
SCHURTER Inc. 3404.0119.11	125 V	0.122 in	7.4 mm	2.6 mm	3.1 mm	0.291 "	0.102 "	Board Mount	2-SMD J-Lead	3.5 A	Slow Blow	cULus	100 A	Surface Mount	11.76	125 VDC	85 °C	-40 °C
SCHURTER Inc. 3403.0122.11	125 V	0.181 in	11 mm	3.9 mm	4.6 mm	0.433 in	0.154 in	Board Mount	2-SMD J-Lead	4 A	Slow Blow		100 A	Surface Mount	23		125 °C	-55 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 A 125 V AC DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, J-Lead
