0393710011

Active

Molex

TERM BLOCK PLUG 11POS STR 7.5MM

Search across all available documentation for this part.

Active

Molex

TERM BLOCK PLUG 11POS STR 7.5MM

Technical Specifications

Parameters and characteristics for this part

Specification	0393710011

Color	Black
Contact Material	Phosphor Bronze
Contact Mating Finish	Tin
Housing Material	Polyamide (PA), Nylon
Insulation Height	0.61 in
Insulation Height	15.49 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Levels	1
Number of Positions	11
Operating Temperature	110 °C
Pitch [x]	0.295 in
Pitch [x]	7.5 mm
Positions Per Level	11
Termination Style	Screw - Rising Cage Clamp
Type	Plug, Female Sockets
Voltage - UL	300 V
Wire Gauge or Range - AWG [Max]	30 AWG
Wire Gauge or Range - AWG [Min]	12 AWG

Part	Type	Contact Material	Termination Style	Number of Levels	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Insulation Height	Insulation Height	Number of Positions	Material Flammability Rating	Voltage - UL	Pitch [x]	Pitch [x]	Positions Per Level	Housing Material	Color	Contact Mating Finish	Mounting Type	Operating Temperature
Molex 0393710010	Plug Female Sockets	Phosphor Bronze	Screw - Rising Cage Clamp	1	30 AWG	12 AWG	0.61 in	15.49 mm	10	UL94 V-0	300 V	0.295 in	7.5 mm	10	Polyamide (PA) Nylon	Black	Tin	Free Hanging (In-Line)	110 °C
Molex 0393710009	Plug Female Sockets	Phosphor Bronze	Screw - Rising Cage Clamp	1	30 AWG	12 AWG	0.61 in	15.49 mm	9	UL94 V-0	300 V	0.295 in	7.5 mm	9	Polyamide (PA) Nylon	Black	Tin	Free Hanging (In-Line)	110 °C
Molex 0393710011	Plug Female Sockets	Phosphor Bronze	Screw - Rising Cage Clamp	1	30 AWG	12 AWG	0.61 in	15.49 mm	11	UL94 V-0	300 V	0.295 in	7.5 mm	11	Polyamide (PA) Nylon	Black	Tin	Free Hanging (In-Line)	110 °C
Molex 0393710007	Plug Female Sockets	Phosphor Bronze	Screw - Rising Cage Clamp	1	30 AWG	12 AWG	0.61 in	15.49 mm	7	UL94 V-0	300 V	0.295 in	7.5 mm	7	Polyamide (PA) Nylon	Black	Tin	Free Hanging (In-Line)	110 °C
Molex 0393710012	Plug Female Sockets	Phosphor Bronze	Screw - Rising Cage Clamp	1	30 AWG	12 AWG	0.61 in	15.49 mm	12	UL94 V-0	300 V	0.295 in	7.5 mm	12	Polyamide (PA) Nylon	Black	Tin	Free Hanging (In-Line)	110 °C
Molex 0393710003	Plug Female Sockets	Phosphor Bronze	Screw - Rising Cage Clamp	1	30 AWG	12 AWG	0.61 in	15.49 mm		UL94 V-0	300 V	0.295 in	7.5 mm	3	Polyamide (PA) Nylon	Black	Tin	Free Hanging (In-Line)	110 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

11 Position Terminal Block Plug, Female Sockets 0.295" (7.50mm) 180° Free Hanging (In-Line)
