CP24S-2E02S

Active

MEAN WELL USA Inc.

22MM/WITHOUT LIGHT/90/IP65/2NC

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

22MM/WITHOUT LIGHT/90/IP65/2NC

Technical Specifications

Parameters and characteristics for this part

Specification	CP24S-2E02S

Approval Agency	CCC, cULus, CE
Circuit	DPST-NC
Current Rating (Amps)	8 A, 2.5 A
Depth Behind Flange [z]	42 mm
Electrical Life	100000 Cycles
Illumination	Non-Illuminated
Ingress Protection	IP66
Mechanical Life	500000 Cycles
Number of Positions	2
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-25 °C
Panel Cutout Dimensions [diameter]	22.3 mm
Switch Function	On-Off
Termination Style	Spring Terminal
Type	Standard
Voltage Rating - AC	120 V
Voltage Rating - DC	30 V

Part	Depth Behind Flange [z]	Mechanical Life	Termination Style	Number of Positions	Voltage Rating - AC	Electrical Life	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating - DC	Ingress Protection	Illumination	Current Rating (Amps)	Switch Function	Panel Cutout Dimensions [diameter]	Approval Agency	Circuit	Type
MEAN WELL USA Inc. CP24S-2E02S	42 mm	500000 Cycles	Spring Terminal	2	120 V	100000 Cycles	70 °C	-25 °C	30 V	IP66	Non-Illuminated	2.5 A 8 A	On-Off	22.3 mm	CCC CE cULus	DPST-NC	Standard

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 11.55

General part information

Selector Switch 2 Position DPST-NC 8A (AC), 2.5A (DC) 120 V Panel Mount
