BD-02BFFA-QL8LN0
ActiveAmphenol LTW
X-LOK, STANDARD SIZE, 5A, 02 PIN
Deep-Dive with AI
Search across all available documentation for this part.
BD-02BFFA-QL8LN0
ActiveAmphenol LTW
X-LOK, STANDARD SIZE, 5A, 02 PIN
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | BD-02BFFA-QL8LN0 |
|---|---|
| Connector Type | Plug Housing |
| Contact Shape | Circular |
| Contact Type | Crimp |
| Features | Backshell |
| Housing Color | Black |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Insert Material | Thermoplastic |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Orientation | Keyed |
| Primary Material | Plastic |
| Shell Size - Insert | B |
| Shielding | Unshielded |
| Type | For Female Sockets |
BD-02BFFA Series
| Part | Primary Material | Shell Size - Insert | Contact Finish - Mating | Mounting Type | Number of Positions | Orientation | Ingress Protection | Current Rating (Amps) | Operating Temperature [Min] | Operating Temperature [Max] | Shielding | Shell Material | Features | Fastening Type | Backshell Material, Plating | Insert Material | Contact Material | Color | Connector Type | Note | Contact Type | Housing Color | Contact Shape | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol LTW | Plastic | B | Gold | Free Hanging (In-Line) | 2 | Keyed | IP66 | 5 A | -40 °C | 105 ░C | Unshielded | Glass Filled Nylon Polyamide (PA) | Backshell Coupling Nut | Bayonet Lock | Glass Filled Nylon Polyamide (PA) | Polyamide (PA) Nylon Glass Filled | Copper Alloy | Black | Female Sockets Plug | |||||
Amphenol LTW | Plastic | B | Free Hanging (In-Line) | 2 | Keyed | IP68 - Dust Tight Waterproof | -40 °C | 105 ░C | Unshielded | Backshell | Thermoplastic | Plug Housing | Contacts Not Included | Crimp | Black | Circular | For Female Sockets | |||||||
Amphenol LTW | Plastic | B | Gold | Free Hanging (In-Line) | 2 | Keyed | IP67 - Dust Tight Waterproof | 5 A | -40 °C | 105 ░C | Unshielded | Glass Filled Nylon Polyamide (PA) | Backshell Coupling Nut | Bayonet Lock | Nylon Polyamide (PA) | Copper Alloy | Black | Female Sockets Plug | ||||||
Amphenol LTW | Plastic | B | Free Hanging (In-Line) | 2 | Keyed | IP68 - Dust Tight Waterproof | -40 °C | 105 ░C | Unshielded | Backshell | Thermoplastic | Plug Housing | Contacts Not Included | Crimp | Black | Circular | For Female Sockets |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 10 | $ 4.48 | |
Description
General part information
BD-02BFFA Series
2 Position Circular Connector Plug Housing Free Hanging (In-Line) Backshell
Documents
Technical documentation and resources
No documents available
