SKA20460

Active

Celduc Inc.

SSR RELAY SPST-NO 5A 24-600V

Search across all available documentation for this part.

Active

Celduc Inc.

SSR RELAY SPST-NO 5A 24-600V

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Input [Max]	Voltage - Input [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Supplier Device Package	Load Current	Termination Style	Approval Agency	Mounting Type	On-State Resistance (Max) [Max]	Voltage - Load [Min]	Voltage - Load [Max]	Output Type	Package / Case
Celduc Inc. SKA20460	30 V	5 V	100 °C	-40 °C	4-SIP	5 A	PC Pin	CE	Through Hole	40 mOhms	24 V	600 V	AC Zero Cross	4-SIP
Celduc Inc. SKA20441	30 V	3 V	100 °C	-40 °C	4-SIP	5 A	PC Pin	CE cURus VDE	Through Hole	40 mOhms	12 V	460 V	AC	4-SIP
Celduc Inc. SKA20421	30 V	3 V	100 °C	-40 °C	4-SIP	5 A	PC Pin	CE cURus VDE	Through Hole	40 mOhms	12 V	275 V	AC	4-SIP

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 29.82

General part information

Solid State SPST-NO (1 Form A) 4-SIP
