XS2MD5242
ActiveOmron Electronics Inc-EMC Div
CONN PLUG MALE 5P GOLD SLDR CUP
Deep-Dive with AI
Search across all available documentation for this part.
XS2MD5242
ActiveOmron Electronics Inc-EMC Div
CONN PLUG MALE 5P GOLD SLDR CUP
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | XS2MD5242 |
|---|---|
| Cable Opening [custom] | 0.63 in |
| Cable Opening [custom] | 16 mm |
| Color | Silver |
| Connector Type | Plug, Male Pins |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 16 Áin |
| Contact Finish Thickness - Mating | 0.41 Ám |
| Contact Material | Brass |
| Current Rating (Amps) | 3 A |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Insert Material | Polybutylene Terephthalate (PBT) |
| Material Flammability Rating | UL94 V-0 |
| Mounting Feature | Bulkhead - Front Side Nut |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Orientation | Keyed |
| Primary Material | Metal |
| Shell Finish | Nickel |
| Shell Material | Brass |
| Shell Size - Insert | M12-5 |
| Voltage Rating | 125 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 18.14 | |
| 10 | $ 15.88 | |||
| 25 | $ 15.20 | |||
| 50 | $ 14.71 | |||
| 100 | $ 14.22 | |||
| 250 | $ 13.43 | |||
| 500 | $ 13.04 | |||
Description
General part information
XS2M Series
5 Position Circular Connector Plug, Male Pins Solder Cup
