PI3586-00-EVAL1

Obsolete

Vicor Corporation

EVALUATION BOARD FOR PI3586-00

Search across all available documentation for this part.

Obsolete

Vicor Corporation

EVALUATION BOARD FOR PI3586-00

Technical Specifications

Parameters and characteristics for this part

Part	Supplied Contents	Voltage - Input [Max]	Voltage - Input [Min]	Voltage - Output	Outputs and Type	Outputs and Type	Regulator Topology	Current - Output	Board Type	Main Purpose	Frequency - Switching	Utilized IC / Part	Mounting Type	Supplier Device Package	Voltage - Input (Max) [Max]	Output Type	Package / Case	Function	Voltage - Output (Max) [Max]	Synchronous Rectifier	Topology	Number of Outputs	Operating Temperature [Min]	Operating Temperature [Max]	Output Configuration	Voltage - Input (Min) [Min]
Vicor Corporation PI3586-00-EVAL1	Board(s)	60 V	30 V	12 V	Non-Isolated	1	Buck	9 A	Fully Populated	DC/DC Step Down	700 kHz	PI3586-00
Vicor Corporation PI3586-00-QFYZ								9 A			700 kHz		Surface Mount	37-GQFN (7x8)	60 V	Adjustable (Fixed)	37-PowerVFQFN Module	Step-Down	14 V		Buck	1	-20 C	120 °C	Positive	30 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

PI3586-00 - DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board

Technical documentation and resources
