JKXEP1G08FQSDS

Active

Souriau-Sunbank by Eaton

CONN RCPT FMALE 8POS GOLD SOLDER

Search across all available documentation for this part.

Active

Souriau-Sunbank by Eaton

CONN RCPT FMALE 8POS GOLD SOLDER

Technical Specifications

Parameters and characteristics for this part

Specification	JKXEP1G08FQSDS

Applications	Audio, Instrumentation, Video, Medical, Telecommunications
Color	Silver
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	0.5 µm
Contact Finish Thickness - Mating	19.7 µin
Current Rating (Amps)	5 A
Fastening Type	Push-Pull
Ingress Protection	IP68 - Dust Tight, Waterproof
Insert Material	Polyphenylene Sulfide (PPS)
Mounting Feature	Bulkhead - Front Side Nut
Mounting Type	Through Hole, Right Angle, Panel Mount
Number of Positions	8
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-50 °C
Orientation	G
Primary Material	Metal
Shell Finish	Chrome over Nickel
Shell Material	Brass
Shell Size - Insert	1
Shielding	Shielded
Termination	Solder

Part	Orientation	Insert Material	Shielding	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Shell Material	Primary Material	Color	Connector Type	Applications	Ingress Protection	Current Rating (Amps)	Mounting Type	Fastening Type	Shell Size - Insert	Termination	Shell Finish	Number of Positions	Contact Finish - Mating	Mounting Feature	Operating Temperature [Min]	Operating Temperature [Max]
Souriau-Sunbank by Eaton JKXEP1G08FQSDS	G	Polyphenylene Sulfide (PPS)	Shielded	0.5 µm	19.7 µin	Brass	Metal	Silver	Receptacle Female Sockets	Audio Instrumentation Medical Telecommunications Video	IP68 - Dust Tight Waterproof	5 A	Panel Mount Right Angle Through Hole	Push-Pull	1	Solder	Chrome over Nickel	8	Gold	Bulkhead - Front Side Nut	-50 °C	125 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

8 Position Circular Connector Receptacle, Female Sockets Solder
