EPM9400RC240-15

Obsolete

Altera

IC CPLD 400MC 15NS 240RQFP

Search across all available documentation for this part.

Obsolete

Altera

IC CPLD 400MC 15NS 240RQFP

Technical Specifications

Parameters and characteristics for this part

Specification	EPM9400RC240-15

Delay Time tpd(1) Max [Max]	15 ns
Mounting Type	Surface Mount
Number of Gates	8000
Number of Logic Elements/Blocks	25
Number of Macrocells	400
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	0 °C
Package / Case	240-BFQFP Exposed Pad
Programmable Type	In System Programmable
Supplier Device Package	240-RQFP (32x32)
Voltage Supply - Internal [Max]	5.25 V
Voltage Supply - Internal [Min]	4.75 V

Part	Supplier Device Package	Number of Gates	Operating Temperature [Max]	Number of Logic Elements/Blocks	Mounting Type	Number of Macrocells	Programmable Type	Delay Time tpd(1) Max [Max]	Voltage Supply - Internal [Min]	Voltage Supply - Internal [Max]	Package / Case	Number of I/O
Altera EPM9400RC240-15	240-RQFP (32x32)	8000	70 °C	25	Surface Mount	400	In System Programmable	15 ns	4.75 V	5.25 V	240-BFQFP Exposed Pad
Altera EPM9400RC208-20	208-RQFP (28x28)	8000	70 °C	25	Surface Mount	400	In System Programmable	20 ns	4.75 V	5.25 V	208-BFQFP Exposed Pad	139
Altera EPM9400RC208-20	208-RQFP (28x28)	8000	70 °C	25	Surface Mount	400	In System Programmable	20 ns	4.75 V	5.25 V	208-BFQFP Exposed Pad	139

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

IC CPLD 400MC 15NS 240RQFP
