AH60P-5

Active

XP POWER

DC DC CONVERTER 6000V 1.5W

Search across all available documentation for this part.

Active

XP POWER

DC DC CONVERTER 6000V 1.5W

Technical Specifications

Parameters and characteristics for this part

Specification	AH60P-5

Applications	ITE (Commercial)
Approval Agency	CE, cURus
Current - Output (Max) [Max]	250 µA
Features	Proportional Output
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	75 ░C
Operating Temperature [Min]	-25 °C
Package / Case	5-DIP Module
Power (Watts)	1.5 W
Size / Dimension [x]	33.8 mm
Size / Dimension [x]	1.33 "
Size / Dimension [y]	11.4 mm
Size / Dimension [y]	0.45 in
Size / Dimension [z]	0.25 "
Size / Dimension [z]	6.4 mm
Standard Number	62368-1
Type	High Voltage - Isolated Module
Voltage - Input (Max) [Max]	5 V
Voltage - Input (Min) [Min]	0.7 V
Voltage - Isolation	500 V
Voltage - Output 1	6000 V

Part	Package / Case	Features	Standard Number	Mounting Type	Voltage - Input (Min) [Min]	Voltage - Output 1	Type	Number of Outputs	Approval Agency	Applications	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Input (Max) [Max]	Power (Watts)	Current - Output (Max) [Max]	Voltage - Isolation	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]
XP POWER AH60P-5	5-DIP Module	Proportional Output	62368-1	Through Hole	0.7 V	6000 V	High Voltage - Isolated Module	1	CE cURus	ITE (Commercial)	-25 °C	75 ░C	5 V	1.5 W	250 µA	500 V	0.25 "	33.8 mm	1.33 "	6.4 mm	11.4 mm	0.45 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

High Voltage - Isolated Module DC DC Converter 1 Output 6000V 250µA 0.7V - 5V Input
