VGS-75C-24
CUI Inc.
AC/DC CONVERTER 24V 77W
Deep-Dive with AI
Search across all available documentation for this part.
VGS-75C-24
CUI Inc.
AC/DC CONVERTER 24V 77W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | VGS-75C-24 |
|---|---|
| Applications | Household Appliances, ITE (Commercial) |
| Approval Agency | CE, cURus |
| Current - Output 1 | 3.2 A |
| Efficiency | 90 % |
| Features | Adjustable Output, Universal Input |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -30 °C |
| Power (Watts) | 77 W |
| Size / Dimension [x] | 3.9 " |
| Size / Dimension [x] | 99 mm |
| Size / Dimension [y] | 97 mm |
| Size / Dimension [y] | 3.82 in |
| Size / Dimension [z] | 1.18 in |
| Size / Dimension [z] | 30 mm |
| Standard Number | 60335-1, 62368-1 |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC, 373 VDC |
| Voltage - Input [Min] | 85 VAC, 120 VDC |
| Voltage - Isolation | 4000 V |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 17.19 | |
| 5 | $ 16.19 | |||
| 10 | $ 15.78 | |||
| 25 | $ 15.25 | |||
| 50 | $ 14.87 | |||
Description
General part information
VGS-75C Series
Enclosed AC DC Converters 1 Output 24V 85 ~ 264 VAC, 120 ~ 373 VDC Input
