1723014

Active

Phoenix Contact

TB, WIRE TO BOARD, 2POS, 30-12AWG, GRN

Search across all available documentation for this part.

Active

Phoenix Contact

TB, WIRE TO BOARD, 2POS, 30-12AWG, GRN

Technical Specifications

Parameters and characteristics for this part

Fixed Terminal Blocks 2P 5.08mm 90DEG

Part	Pitch [x]	Pitch [x]	Mounting Type	Color	Wire Gauge [Max]	Wire Gauge [Min]	Screw Thread	Wire Termination	Mating Orientation	Housing Material	Current	Positions Per Level	Torque - Screw [Max]	Torque - Screw [Max]	Torque - Screw [Min]	Torque - Screw [Min]	Features	Number of Levels [custom]	Voltage
Phoenix Contact 1723014	0.2 in	5.08 mm	Through Hole	Green	30 AWG	12 AWG	M3	Screw - Rising Cage Clamp	Horizontal with Board	Polyamide (PA) Nylon	20 A	2	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	Interlocking (Side)	3	300 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fixed Terminal Blocks 2P 5.08mm 90DEG
