BU-5144-A-4-0
ActiveMueller Electric Co
TEST LEAD, BNC PLUG TO PIN TIP PLUG X 2, BLACK, 300 VRMS, 5 A, 101.6 MM
Deep-Dive with AI
Search across all available documentation for this part.
BU-5144-A-4-0
ActiveMueller Electric Co
TEST LEAD, BNC PLUG TO PIN TIP PLUG X 2, BLACK, 300 VRMS, 5 A, 101.6 MM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | BU-5144-A-4-0 |
|---|---|
| 1st Connector | BNC, Male Plug |
| 2nd Connector | Banana Plug, Single, Stackable (2) |
| Cable Length [x] | 4 in |
| Cable Length [x] | 101.6 mm |
| Configuration | BNC to Banana |
| Current Rating (Amps) | 5 A |
| Material - Insulation | Poly-Vinyl Chloride (PVC) |
| Temperature Range | 105 °C |
| Temperature Range | 221 °F |
| Voltage - Rated | 300 VAC |
| Wire Gauge | 20 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
BU-5144 Series
4.0" (101.60mm) BNC, Male Plug To Banana Plug, Single, Stackable (2) Test Lead 300VAC
