HDF-V62-213L011

Active

MH Connectors

CONN D-SUB HD RCPT 62POS PNL MNT

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

HDF-V62-213L011

Active

MH Connectors

CONN D-SUB HD RCPT 62POS PNL MNT

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	HDF-V62-213L011

Color	Black
Connector Style	High Density, D-Sub
Connector Type	Receptacle, Female Sockets
Contact Finish	Gold
Contact Finish Thickness	Flash
Contact Material	Brass
Contact Type	Signal
Current Rating (Amps)	3 A
Dielectric Material	Polybutylene Terephthalate (PBT)
Flange Feature	Female Screwlock (4-40), Mating Side
Ingress Protection	IP67 - Dust Tight, Waterproof
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole, Panel Mount
Number of Positions	62
Number of Rows	3
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Shell Material, Finish	Nickel Plated, Steel
Shell Size, Connector Layout	4
Termination	Solder

HDF-V62 Series

Part	Contact Material	Dielectric Material	Number of Rows	Connector Style	Shell Size, Connector Layout	Ingress Protection	Mounting Type	Number of Positions	Contact Finish	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Type	Color	Material Flammability Rating	Current Rating (Amps)	Contact Finish Thickness	Contact Finish Thickness	Termination	Shell Material, Finish	Flange Feature	Features	Contact Finish Thickness
MH Connectors HDF-V62-213L012	Brass	Polybutylene Terephthalate (PBT)	3	D-Sub High Density	4	IP67 - Dust Tight Waterproof	Panel Mount Through Hole	62	Gold	Receptacle Female Sockets	-25 °C	85 °C	Signal	Black	UL94 V-0	3 A	0.76 Ám	30 Áin	Solder	Nickel Plated Steel	Female Screwlock (4-40) Mating Side
MH Connectors HDF-V62-113L052	Brass	Polybutylene Terephthalate (PBT)	3	D-Sub High Density	4	IP67 - Dust Tight Waterproof	Panel Mount Through Hole	62	Gold	Male Pins Plug	-25 °C	85 °C	Signal	Black	UL94 V-0	3 A	0.76 Ám	30 Áin	Solder	Nickel Plated Steel	Female Screwlock (4-40) Mating Side	Board Lock Grounding Indents
MH Connectors HDF-V62-213L052	Brass	Polybutylene Terephthalate (PBT)	3	D-Sub High Density	4	IP67 - Dust Tight Waterproof	Panel Mount Through Hole	62	Gold	Receptacle Female Sockets	-25 °C	85 °C	Signal	Black	UL94 V-0	3 A	0.76 Ám	30 Áin	Solder	Nickel Plated Steel	Female Screwlock (4-40) Mating Side
MH Connectors HDF-V62-113L012	Brass	Polybutylene Terephthalate (PBT)	3	D-Sub High Density	4	IP67 - Dust Tight Waterproof	Panel Mount Through Hole	62	Gold	Male Pins Plug	-25 °C	85 °C	Signal	Black	UL94 V-0	3 A	0.76 Ám	30 Áin	Solder	Nickel Plated Steel	Female Screwlock (4-40) Mating Side	Grounding Indents
MH Connectors HDF-V62-213L051	Brass	Polybutylene Terephthalate (PBT)	3	D-Sub High Density	4	IP67 - Dust Tight Waterproof	Panel Mount Through Hole	62	Gold	Receptacle Female Sockets	-25 °C	85 °C	Signal	Black	UL94 V-0	3 A			Solder	Nickel Plated Steel	Female Screwlock (4-40) Mating Side		Flash
MH Connectors HDF-V62-213L011	Brass	Polybutylene Terephthalate (PBT)	3	D-Sub High Density	4	IP67 - Dust Tight Waterproof	Panel Mount Through Hole	62	Gold	Receptacle Female Sockets	-25 °C	85 °C	Signal	Black	UL94 V-0	3 A			Solder	Nickel Plated Steel	Female Screwlock (4-40) Mating Side		Flash
MH Connectors HDF-V62-113L011	Brass	Polybutylene Terephthalate (PBT)	3	D-Sub High Density	4	IP67 - Dust Tight Waterproof	Panel Mount Through Hole	62	Gold	Male Pins Plug	-25 °C	85 °C	Signal	Black	UL94 V-0	3 A			Solder	Nickel Plated Steel	Female Screwlock (4-40) Mating Side	Grounding Indents	Flash
MH Connectors HDF-V62-113L051	Brass	Polybutylene Terephthalate (PBT)	3	D-Sub High Density	4	IP67 - Dust Tight Waterproof	Panel Mount Through Hole	62	Gold	Male Pins Plug	-25 °C	85 °C	Signal	Black	UL94 V-0	3 A			Solder	Nickel Plated Steel	Female Screwlock (4-40) Mating Side	Board Lock Grounding Indents	Flash

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 22.46
		10	$ 17.31
		25	$ 15.67
		40	$ 14.90
		80	$ 13.87
		230	$ 12.47
		440	$ 11.71

Description

General part information

HDF-V62 Series

62 Position D-Sub, High Density Receptacle, Female Sockets Connector
