PET-7250A

Active

ICP DAS USA INC

MODBUS TCP, 12CH DI, 6CH DO

Search across all available documentation for this part.

Active

ICP DAS USA INC

MODBUS TCP, 12CH DI, 6CH DO

Technical Specifications

Parameters and characteristics for this part

Specification	PET-7250A

Approval Agency	CE
Mounting Type	DIN Rail
Number of Inputs and Type [custom]	Digital
Number of Inputs and Type [custom]	12
Number of Outputs and Type [custom]	Digital
Number of Outputs and Type [custom]	6
Operating Temperature [Max]	75 ░C
Operating Temperature [Min]	-25 °C
Termination Style	Screw Terminal
Type	Input, Output (I/O) Module
Voltage - Supply [Max]	48 V
Voltage - Supply [Min]	12 V

Part	Mounting Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Termination Style	Approval Agency	Number of Outputs and Type [custom]	Number of Outputs and Type [custom]	Operating Temperature [Min]	Operating Temperature [Max]	Number of Inputs and Type [custom]	Number of Inputs and Type [custom]	Type	Features	Number of Outputs and Type	Number of Outputs and Type	Number of Outputs and Type [custom]	Number of Outputs and Type [custom]	Number of Inputs and Type [custom]	Number of Inputs and Type [custom]
ICP DAS USA INC PET-7019Z/S2	DIN Rail	12 V	48 V	Screw Terminal	CE	Digital	6	-25 °C	75 ░C	Analog	10	Input Output (I/O) Module
ICP DAS USA INC PET-7218Z/S	DIN Rail	12 V	48 V	Screw Terminal	CE			-25 °C	75 ░C	Analog	10	Input Output (I/O) Module	B C E J K L M N R S T	Digital	3
ICP DAS USA INC PET-7250A	DIN Rail	12 V	48 V	Screw Terminal	CE	Digital	6	-25 °C	75 ░C	Digital	12	Input Output (I/O) Module
ICP DAS USA INC PET-7019Z/S	DIN Rail	12 V	48 V	Screw Terminal	CE	Digital	6	-25 °C	75 ░C	Analog	10	Input Output (I/O) Module
ICP DAS USA INC PET-7H24M	DIN Rail	12 V	48 V	RJ45 Screw Terminal	CE			-25 °C	75 ░C			Input Output (I/O) Module				4	2	4	3
ICP DAS USA INC PET-7H16M	DIN Rail	12 V	48 V	RJ45 Screw Terminal	CE			-25 °C	75 ░C			Input Output (I/O) Module		Digital	4			8	4
ICP DAS USA INC PET-7018Z/S	DIN Rail	12 V	48 V	Screw Terminal	CE	Digital	6	-25 °C	75 ░C			Input Output (I/O) Module
ICP DAS USA INC PET-7018Z/S2	DIN Rail	12 V	48 V	Screw Terminal	CE	Digital	6	-25 °C	75 ░C			Input Output (I/O) Module

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 419.00

General part information

Input, Output (I/O) Module DIN Rail 12 ~ 48VDC

Technical documentation and resources

No documents available
