22CC50C0875B

Active

Essentra Access Solutions

FASTENER, SCREW MOUNT CABLE CLAMP, 0.875 ", NYLON 6.6 (POLYAMIDE 6.6), BLACK, 0.5 "

Search across all available documentation for this part.

Active

Essentra Access Solutions

FASTENER, SCREW MOUNT CABLE CLAMP, 0.875 ", NYLON 6.6 (POLYAMIDE 6.6), BLACK, 0.5 "

Technical Specifications

Parameters and characteristics for this part

Specification	22CC50C0875B

Bundle Center to Mounting Center	0.845 in
Bundle Center to Mounting Center	21.46 mm
Color	Black
Material	Polyamide (PA66), Nylon 6/6
Material Flammability Rating	UL94 V-2
Material Thickness	0.05 in
Material Thickness	1.27 mm
Mounting Type	Fastener
Opening Size	22.23 mm
Opening Size [z]	0.875 in
Panel Hole Size [diameter]	4.24 mm
Panel Hole Size [diameter]	0.167 in
Type	Clamp, P-Type

Part	Opening Size [z]	Opening Size	Mounting Type	Material Flammability Rating	Bundle Center to Mounting Center	Bundle Center to Mounting Center	Type	Material Thickness	Material Thickness	Color	Panel Hole Size [diameter]	Panel Hole Size [diameter]	Material	Opening Size [custom]	Opening Size [custom]
Essentra Access Solutions 22CC50C0875B	0.875 in	22.23 mm	Fastener	UL94 V-2	0.845 in	21.46 mm	Clamp P-Type	0.05 in	1.27 mm	Black	4.24 mm	0.167 in	Polyamide (PA66) Nylon 6/6
Essentra Access Solutions 22CC50C0187			Fastener	UL94 V-2			Clamp P-Type	0.05 in	1.27 mm	Natural	4.24 mm	0.167 in	Polyamide (PA66) Nylon 6/6	0.187 in	4.75 mm
Essentra Access Solutions 22CC50C0125	0.125 in	3.18 mm	Fastener	UL94 V-2			Clamp P-Type	0.05 in	1.27 mm	Natural	4.24 mm	0.167 in	Polyamide (PA66) Nylon 6/6

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

P style screw mount nylon cable clamp used for securing cable bundles.
