VMMK-1218-BLKG
ObsoleteBroadcom Limited
RF MOSFET E-PHEMT 3V 0402
Deep-Dive with AI
Search across all available documentation for this part.
VMMK-1218-BLKG
ObsoleteBroadcom Limited
RF MOSFET E-PHEMT 3V 0402
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | VMMK-1218-BLKG |
|---|---|
| Current - Test | 20 mA |
| Current Rating (Amps) | 100 mA |
| Frequency | 10 GHz |
| Gain | 9 dBi |
| Noise Figure | 0.81 dB |
| Package / Case | 0402 (1005 Metric) |
| Power - Output | 12 dBm |
| Supplier Device Package | 0402 |
| Technology | E-pHEMT |
| Voltage - Rated | 5 V |
| Voltage - Test | 3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
VMMK-1218 Series
RF Mosfet 3 V 20 mA 10GHz 9dB 12dBm 0402
Documents
Technical documentation and resources
No documents available
