25010/15 RD199

Active

ALPHA WIRE

CABLE 15COND 22AWG RED 1000'

Search across all available documentation for this part.

Active

ALPHA WIRE

CABLE 15COND 22AWG RED 1000'

Technical Specifications

Parameters and characteristics for this part

Specification	25010/15 RD199

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Features	Rip Cord, Biological Compatibility
Jacket (Insulation) Diameter [diameter]	0.299 in
Jacket (Insulation) Diameter [diameter]	7.6 mm
Jacket (Insulation) Material	Polyurethane (PU)
Jacket Color	Red
Number of Conductors	15
Operating Temperature [Max]	90 °C
Operating Temperature [Min]	-30 ░C
Ratings	UL Style 20668, ISO 10993
Voltage	300 V
Wire Gauge	22 AWG

Part	Operating Temperature [Min]	Operating Temperature [Max]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Voltage	Ratings	Number of Conductors	Jacket (Insulation) Material	Conductor Material	Cable Type	Conductor Insulation	Features	Wire Gauge	Conductor Strand [custom]	Conductor Strand [custom]	Length	Length
ALPHA WIRE 25010/15 RD199	-30 ░C	90 °C	0.299 in	7.6 mm	Red	300 V	ISO 10993 UL Style 20668	15	Polyurethane (PU)	Copper Tinned	Multi-Conductor	Poly-Vinyl Chloride (PVC)	Biological Compatibility Rip Cord	22 AWG	7	30 AWG
ALPHA WIRE 25010/15 BK199	-30 ░C	90 °C	0.299 in	7.6 mm	Black	300 V	ISO 10993 UL Style 20668	15	Polyurethane (PU)	Copper Tinned	Multi-Conductor	Poly-Vinyl Chloride (PVC)	Biological Compatibility Rip Cord	22 AWG	7	30 AWG	1000 ft	304.8 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 9.28

General part information

15 Conductor Multi-Conductor Cable Red 22 AWG
