1808433

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS TFKC2,5/3-STF-5,08BK

Search across all available documentation for this part.

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS TFKC2,5/3-STF-5,08BK

Technical Specifications

Parameters and characteristics for this part

Specification	1808433

Color	Black
Contact Material	Copper Alloy
Contact Mating Finish	Tin
Current - IEC	12 A
Current - UL	10 A
Features	Push Button Actuated, Mating Flange
Housing Material	Polyamide (PA), Nylon
Insulation Height	0.87 in
Insulation Height	22.1 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Levels	1
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Pitch [x]	0.2 in
Pitch [x]	5.08 mm
Positions Per Level	3
Termination Style	Push-In Spring, Screwless - Leg Spring
Type	Plug, Female Sockets
Voltage - IEC	320 V
Voltage - UL	300 V
Wire Gauge or Range - AWG [Max]	26 AWG
Wire Gauge or Range - AWG [Min]	12 AWG
Wire Gauge or Range - mm² [Max]	1.5 mm²
Wire Gauge or Range - mm² [Min]	0.2 mm²
Wire Strip Length	10 mm

Pluggable Terminal Blocks TFKC 2,5/ 2-ST- 5,08 BD:1-4Q

Part	Current - IEC	Housing Material	Wire Gauge or Range - mm² [Min]	Wire Gauge or Range - mm² [Max]	Wire Strip Length	Pitch [x]	Pitch [x]	Material Flammability Rating	Contact Mating Finish	Color	Number of Levels	Type	Voltage - IEC	Positions Per Level [custom]	Positions Per Level [custom]	Insulation Height	Insulation Height	Termination Style	Wire Gauge or Range - AWG [Min]	Wire Gauge or Range - AWG [Max]	Mounting Type	Current - UL	Voltage - UL	Positions Per Level	Operating Temperature [Max]	Operating Temperature [Min]	Number of Levels	Features	Contact Material
Phoenix Contact 1962639	12 A	Polyamide (PA) Nylon	0.2 mm²	2.5 mm²	10 mm	0.2 in	5.08 mm	UL94 V-0	Tin	Green	1 (Mate) 2 (Input)	Plug Female Sockets	630 V	5	10	0.87 in	22.1 mm	Screwless - Push-In Spring	12 AWG	26 AWG	Free Hanging (In-Line)	10 A	300 V
Phoenix Contact 1808433	12 A	Polyamide (PA) Nylon	0.2 mm²	1.5 mm²	10 mm	0.2 in	5.08 mm	UL94 V-0	Tin	Black		Plug Female Sockets	320 V			0.87 in	22.1 mm	Push-In Spring Screwless - Leg Spring	12 AWG	26 AWG	Free Hanging (In-Line)	10 A	300 V	3	100 °C	-40 °C	1	Mating Flange Push Button Actuated	Copper Alloy

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pluggable Terminal Blocks TFKC 2,5/ 2-ST- 5,08 BD:1-4Q
