Q2-F-1/16-01-SS1000FT

Active

Qualtek

HEATSHRINK POLY 1/16" BLK 1000'

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsPart Numbering Guide Datasheet +1

Q2-F-1/16-01-SS1000FT

Active

Qualtek

HEATSHRINK POLY 1/16" BLK 1000'

Deep-Dive with AI

DocumentsPart Numbering Guide Datasheet +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q2-F-1/16-01-SS1000FT

Color	Black
Features	Flame Retardant
Inner Diameter - Recovered [diameter]	0.79 mm
Inner Diameter - Recovered [diameter]	0.031 in
Inner Diameter - Supplied [diameter]	0.063 in
Inner Diameter - Supplied [diameter]	1.6 mm
Length	0.062 ', 0.125 ', 0.083 ft, 1000 ft
Length	19.05 mm, 38.1 mm, 25.4 mm, 304.8 m
Length	0.75 ", 1.5 ", 1 in
Length	Enter Number of Feet in Order Quantity
Material	Polyolefin (PO)
Operating Temperature [Max]	135 °C
Operating Temperature [Min]	-55 °C
Recovered Wall Thickness	0.016 "
Recovered Wall Thickness	0.41 mm
Shelf Life	144 Months
Shelf Life Start	Date of Manufacture
Shrink Temperature	70 °C
Shrinkage Ratio	2 to 1
Spool Size	1000 ft
Spool Size	304.8 m
Storage/Refrigeration Temperature [Max]	40 °C
Storage/Refrigeration Temperature [Min]	-10 °C, -50 °F
Type	Tubing, Flexible

Q2-F-1/16 Series

Part	Shrink Temperature	Material	Features	Shrinkage Ratio	Recovered Wall Thickness	Recovered Wall Thickness	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Max]	Shelf Life	Operating Temperature [Max]	Operating Temperature [Min]	Type	Length [x]	Length [x]	Shelf Life Start	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Color	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Length	Length	Length	Spool Size	Spool Size	Length	Length
Qualtek Q2-F-1/16-01-QB48IN-25	70 °C	Polyolefin (PO)	Flame Retardant	2 to 1	0.016 "	0.41 mm	-50 °F -10 °C	40 °C	144 Months	135 °C	-55 °C	Tubing Flexible	1.22 m	4 ft	Date of Manufacture	0.063 in	1.6 mm	Black	0.79 mm	0.031 in
Qualtek Q2-F-1/16-01-MS100FT	70 °C	Polyolefin (PO)	Flame Retardant	2 to 1	0.016 "	0.41 mm	-50 °F -10 °C	40 °C	144 Months	135 °C	-55 °C	Tubing Flexible	30.5 m	100 ft	Date of Manufacture	0.063 in	1.6 mm	Black	0.79 mm	0.031 in
Qualtek Q2-F-1/16-01-SS1000FT	70 °C	Polyolefin (PO)	Flame Retardant	2 to 1	0.016 "	0.41 mm	-50 °F -10 °C	40 °C	144 Months	135 °C	-55 °C	Tubing Flexible			Date of Manufacture	0.063 in	1.6 mm	Black	0.79 mm	0.031 in	0.062 ' 0.083 ft 0.125 ' 1000 ft	19.05 mm 25.4 mm 38.1 mm 304.8 m	0.75 " 1 in 1.5 "	1000 ft	304.8 m	Enter Number of Feet in Order Quantity
Qualtek Q2-F-1/16-01-QB6IN-36	70 °C	Polyolefin (PO)	Flame Retardant	2 to 1	0.016 "	0.41 mm	-50 °F -10 °C	40 °C	144 Months	135 °C	-55 °C	Tubing Flexible				0.063 in	1.6 mm	Black	0.79 mm	0.031 in		152.4 mm	6 "				0.5 '
Qualtek Q2-F-1/16-01-QX50FT	70 °C	Polyolefin (PO)	Flame Retardant	2 to 1	0.016 "	0.41 mm	-50 °F -10 °C	40 °C	144 Months	135 °C	-55 °C	Tubing Flexible				0.063 in	1.6 mm	Black	0.79 mm	0.031 in	50 ft	15.2 m

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	50	$ 0.02
		50	$ 0.03
		50	$ 0.03
		50	$ 0.02
		100	$ 0.02
		100	$ 0.02
		100	$ 0.03
		100	$ 0.02
		250	$ 0.02
		250	$ 0.02
		250	$ 0.02
		250	$ 0.02
		500	$ 0.02
		500	$ 0.02
		500	$ 0.02
		500	$ 0.02
		1250	$ 0.02
		1250	$ 0.02
		1250	$ 0.02
		1250	$ 0.02
	Digi-Spool®, Continuous Spool	1	$ 0.59
		5	$ 0.53
		10	$ 0.41
		25	$ 0.38
		50	$ 0.36
		100	$ 0.34
	Spool	1	$ 62.35
		5	$ 58.45
		10	$ 54.55
		25	$ 51.82
		50	$ 50.66
		100	$ 49.49

Description

General part information

Q2-F-1/16 Series

Heat Shrink Tubing, Flexible 0.063" (1.60mm) 2 to 1 Black 1000.0' (304.8m)

Documents

Technical documentation and resources

Part Numbering Guide

Datasheet
